Ohmic coil - Eindhoven Primary
Monday, February 01 2010 10:22
Daniel Eindhoven
|
|
A new composition of the primary coil for a Double Resonance Solid State TeslaCoil (DRSSTC). It is a combination of wire and capacitors. By making the coil like this you get rid of all the parasitic inductions of the capacitor bank, it reduces wire length and saves a lot of space. Calculating the resonance frequency also becomes much easier. I hereby dub this coil configuration: The Eindhoven Primary.
|
Read more...
|
Solar Beetle
Tuesday, December 29 2009 13:32
Daniel Eindhoven
|
|
A fairly old project
that I still had to post. A small car on solar power. It contains a circuit which charges a capacitor, when it's full the capacitor gets discharged trough the electric motor.
The left half of the
solar panel is connected to the right motor and vice versa. This way he always turns
to the light. Vehicles that exhibit
this behavior are also known as Braitenberg vehicles. |
Read more...
Transparent Mini DC TeslaCoil
Thursday, November 05 2009 20:33
Daniel Eindhoven
|
A small TeslaCoil fully made of acrylic plastic. The cool thing about this is that every part is transparent. This coil is driven by the power supply of my large DC Teslacoil. Total height 44cm, max output voltage +- 380.000 Volts (57cm arc length).
|
Read more...
Cascade Voltage Multiplier 30kV
Sunday, October 25 2009 14:27
Daniel Eindhoven
 |
A Voltage Multiplier made from Microwave parts. 30 Microwaves where demolished for this project. |
Read more...
MV Speedometer
Monday, September 28 2009 18:35
Daniel Eindhoven
 |
A speedometer specially designed for coilgun projectiles! To determine the speed of coilgun projectiles while experimenting, I usually counted the frames of my high speed camera while filming the projectile. Now using 2 optical sensors and a microcontroller I can calculate the velocity and kinetic energy of the projectile and read it directly on the display. A large improvement! |
Read more...
MV CoilMaster Mark1 CoilGun
Tuesday, June 16 2009 00:00
Daniel Eindhoven
 |
The Weapon of the future, shooting steel bullets on pure electricity!! This type of weapon is also referred to as coil gun or gauss gun. |
Read more...
Thunder pictures
Tuesday, June 16 2009 07:35
Daniel Eindhoven
 | Here you can find all pictures I made during thunderstorms. Nothing mutch yet, but there is improvement. |
Read more...
|
|
